Our jaw crusher is a primary crushing equipment widely used in mining, construction, and metallurgy.It has the features of high crushing ratio, larger capacity, even final product size, simple structure, reliable performance, convenient maintenance, lower operation cost, etc.
The jaw crusher is designed with advanced technology, adopting a rugged structure to ensure long-term reliable operation. It is mainly used for crushing large-sized rocks and ores into medium or small particles. With adjustable discharge opening, it can meet different crushing requirements of customers. The equipment has low energy consumption, easy maintenance, and strong crushing capacity, making it an ideal primary crushing device for various industrial fields such as mining, road construction, and building materials production. It can handle materials with compressive strength up to 320MPa, including granite, basalt, limestone, and more.
High crushing ratio. even final product size;
Adjusting wedge makes discharging opening have wide adjustable range. reliable and convenient, thus it is capable to meet various requirements of customers;
Lubrication system is safe and reliable, easily to replace the parts and small maintenance workload;
Simple structure, reliable performance, low maintenance and operating cost;
Little dust and low noise.
| Model | Feeding opening size(mm) | Max feeding size(mm) | Discharging opening size(mm) | Capacity(t/h)n | Motor power(kw)n | We1ght(t)n | Overall dimension(L×W×H) (mm)n |
|---|---|---|---|---|---|---|---|
| PE-250×400 | 250×400 | 210 | 20-60 | 5-20 | 15 | 2.8 | 1180×1087×1245 |
| PE-400×600 | 400×600 | 340 | 40-100 | 16-60 | 30 | 6.65 | 1797×1716×1581 |
| PE-500×750 | 500×750 | 425 | 50-100 | 40-110 | 55 | 11.73 | 2119×1918×2046 |
| PE-600×900 | 600×900 | 500 | 65-180 | 80-180 | 55-75 | 16.13 | 2309×2028×2368 |
| PE-750×1060 | 750×1060 | 630 | 80-180 | 110-320 | 90-110 | 30 | 2730×2472×2840 |
| PE-870×1060 | 870×1060 | 750 | 170-270 | 180-360 | 90-110 | 31.22 | 2990×2416×2893 |
| PE-900×1200 | 900×1200 | 780 | 95-225 | 220-450 | 110-132 | 49 | 3362×2750×3260 |
| PE-1000×1200 | 1000×1200 | 850 | 195-280 | 280-550 | 110-132 | 51 | 3823×2938×3285 |
| PE-1200×1500 | 1200×1500 | 1020 | 150-300 | 400-800 | 160-220 | 100.9 | 4930×3334×4057 |
| PEX-150×750 | 150×750 | 120 | 18-48 | 8-25 | 15 | 3.5 | 1252×1593×1025 |
| PEX-250×750 | 250×750 | 210 | 20-50 | 13-35 | 30 | 4.96 | 1435×1832×1715 |
| PEX-250×1000 | 250×1000 | 210 | 25-60 | 16-52 | 30-37 | 6.5 | 1706×1964×1380 |
| PEX-250×1200 | 250×1200 | 210 | 25-60 | 20-61 | 37-45 | 8.8 | 1700×2132×1450 |
| PEX-300×1300 | 300×1300 | 250 | 20-90 | 25-95 | 55-75 | 12.6 | 2026×2320×1723 |
*Note：Technical parameters are subject to change without notice.
Fill your requirements here, and we'll send the custmized solution and quotation to you by the reserved contact information.
